SPECIFICATIONS
- Amplier at rated conditions, both channels driven, 8Ω loads, unless otherwise specied.
Notes:
- Depending on the ambient temperature, the unit might not operate continuously at 2Ω load.
- Due to mains voltage in Japan (100V/50Hz) the values for the maximum output power can be decreased up to 10% (only
100V version)!
CP3000S
Load Impedance 2Ω 4Ω 8Ω
Maximum Midband Output Power
THD = 1%, 1kHz, Dual Channel
1600W 1100W 600W
Rated Output Power
THD < 0.1%, 20Hz ... 20kHz
-- 900W 450W
Max. Single Channel Output Power
Dynamic-Headroom, IHF-A
2600W 1400W 720W
Max. Single Channel Output Power
Continuous, 1kHz
2100W 1300W 660W
Max. Bridged Output Power
THD = 1%, 1kHz
-- 3200W 2200W
Maximum RMS Voltage Swing
THD = 1%, 1kHz
78V
Power Bandwith
THD = 1%, ref. 1kHz, half power @ 4Ω
10Hz ... 60kHz
Voltage Gain
ref. 1kHz
32,0 dB
Input Sensitivity
at rated output power
+5.8 dBu (1.51 V rms)
THD at rated output power,
MBW = 80kHz, 1kHz
< 0.05%
IMD-SMPTE
60Hz, 7kHz
< 0.02%
DIM30
3.15kHz, 15kHz
< 0.05%
Maximum Input Level
+22dBu (9.76 Vrms)
Crosstalk
ref. 1kHz, at rated output power
< - 80dB
Frequency Response
-1dB, ref. 1kHz
15Hz ... 40kHz
Input Impedance
active balanced
20kΩ
Damping Factor
1kHz
> 300
Slew Rate
35 V/ms
Signal to Noise Ratio, Amplier
A-weighted
107 dB
Output Stage Topology
Class H
Power Requirements
240, 230, 220, 120V or 100V; 50Hz ... 60 Hz (factory congured)
Power Consumption
1/8 maximum output power @ 4Ω
820W
Protection
Audio limiters, High temperature, DC, HF, Back-EMF,
Peak current limiters, Inrush current limiters, Turn-on delay
Cooling
Front-to rear, 3-stage-fans
Ambient Temperature Limits
+5°C ... +40°C ( 40°F ... 105°F)
Safety Class
I
Dimensions
(W x H x D), mm
483 x 88,1 x 386,8
Weight
8.15 kg (18.0 Ibs)
Optional:
Rear-rackmount 15,5“
Rear-rackmount 18“
(NRS 90262) 112930
(NRS 90264) 112933
