SPECIFICATIONS
R300 Receiver
ReceiverType SynthesizedPLL
FrequencyRange(RF)
ABand618–634MHz 
BBand678–694MHz
CBand516–532MHz 
EBand850–865MHz
NumberofChannels 32
Modulation +/-40kHz
Diversity Antenna
RFSensitivity <1.0μVfor12dBSINAD
ImageRejection >55dB
Squelch ToneCodeplusAmplitude
FCCCertication ApprovedunderPart15
PowerRequirements 12-16VDC,500mAmax
OperatingTemperature 5ºto45ºC(41ºto113ºF)
Dimensions
1.72inHx7.8inWx8.0inD
(43mmHx206mmWx210mmD)
