DETAILED COMPONENT DESCRIPTIONS
2.1 | R300 Receiver
RECEIVER CONTROLS, CONNECTORS
1. PowerON/OFF
2. SYNCDataTransferButton
3. InfraredEZsyncWindow
4. GraphicalDisplay
a.ChannelorFrequencyDisplay
b.DiversityIndicator
c. RFStrengthMeter
d.AudioLevelMeter
e. LockIndicator
f. SquelchLevelIndicator
5. ScrollDownandUp( and )ControlButtons
6. SETControlButton
7. ClearScanControl(pressandhold button)
8. TNCAntennaInputConnectors(2)
9. AudioOutputVolumeControl
10. XLRBalancedOutputConnector
11. ¼InchUnbalancedLineLevelAudioOutputConnector
12. UnbalancedOutputLevelSwitch(-10dBor0dB)
13. DCPowerConnector(12VDC,500mA)
14. PowerCordRetainer
02
8 89 10
11
12 13 14
