UHF Wireless RE3-RX r eceiver | en 35
-Voice Installation manual 2021.06 | 03 | F.01U.362.808
4 Press SET to save changes and return to main menu.
5
Either scroll ▼down to Exit and press SET, or briefly press
SYNC on the receiver front panel to return to the home
screen.
OR
7.3.12 Adjusting receiver output level
Setting the receiver output level through menu item 7, RX Output Level assigns either mic
level, or line level to the receiver XLR and ¼” TS output jacks. This is an important step in
ensuring the signal level leaving the receiver is appropriate for the destination circuit of
either a microphone preamp, or a line in preamp.
1
Press the
button to scroll down to RX Output Level from
the main menu. Select by pressing SET to enter the RX
Output Level screen.
2
The display shows the current volume setting of either MIC or
LINE.
3
To select desired level, pressing the ▲ button toggles from
MIC to LINE, and the ▼ button toggles from LINE to MIC.
4 Press SET to save changes and return to main menu.
5
Either scroll ▼down to Exit and press SET, or briefly press
SYNC on the receiver front panel to return to the home
screen.
OR
7.3.13 Turning antenna power on and off
The receiver antenna jacks can supply 12vDC booster feed to power the optional RFAMP
booster, or ALPA active antenna.
