6.3.3 MAIN MENU FUNCTIONS DESCRIPTION
Main Menu
Submenu
Description
Range
Default
Lingua/Language
Italiano / English /
Spanish / Swedish /
Russian
Display language - Default: English
NOTE: only N°3 languages for
ITTP(D) 4-5.5-7.5; the indicated
languages may change depending on
the sales country.
Italiano / English
/ Spanish /
Swedish /
Russian
English
Date adjurnment
Day [dd]
Month [MM]
Year [yy]
Hour [hh]
Minute [mm]
Second [ss]
Allow to do the data regulation (day –
month – year) and the time (hour –
minute – second). It Is important to
set in following conditions:
9
Single Pump with
programming;
10
Group of pumps in Master-
Slave.
Pressure
reference /
Differential
Pressure
reference
(dP=P2-P1)
Set P1(dP1): _._
[BAR]
Set P2(dP2): _._
[BAR]
Set P3(dP3): _._
[BAR]
Set P4(dP4): _._
[BAR]
N°4 set-point for absolute pressure
reference and for the Differential
Pressure reference;
The same parameter can change
directly during pump functioning,
pushing “+” or “-“ on the control
panel.
Absolute:
1.0 .. Pmax
Differential:
0.1 .. Pmax
Absolute:
*(3bar)
P1=4.0 bar
P2=3.0 bar
P3=2.0 bar
P4=1.5 bar
Differential:
*(3bar)
dP1=0.40 bar
dP2=0.30 bar
dP3=0.20 bar
dP4=0.15 bar
Motor data
(PASSWORD
required)
1. Nominal Power
[kW]
2. Nominal Voltage
[V]
3. Nominal Current
[A]
4. Rotation [0/1]
5. Nominal
Frequency [Hz]
6. Nominal RPM
7. P.F.
8. Minimum Flow
stop power [%]
9. Dry Working stop
power [%]
1. Nominal Power: motor rated
power (read motor label)
2. Nominal Voltage: motor rated
voltage
3. Nominal Current: motor rated
current, according to the motor
phases connection in use
(star/delta, see 5.4).
4. Rotation direction (0/1)
5. Nominal Frequency of the Motor
6. Nominal RPM motor (read on the
motor label) *(not for 2.2M);
7. *(6) Power Factor of the motor
(read motor label);
8. *(7) Power value for the
minimum flow protection (%
referring to the value measured
during check with closed
delivery) – Not active for
Differential pressure control;
9. *(8) Power value for the dry
working protection (% referring to
the value measured during check
with closed delivery)
0.1 .. Pot max
*(210 .. 440V)
200 .. 440V
0.1 .. I max
0 / 1
*(50 .. 140Hz)
60 .. 140 Hz
700..3552 RPM
*(0.50 .. 0.95)
0.60 .. 0.95
*(50 .. 150%)
10 .. 150%
*(30 .. 100%)
0 .. 100%
230V for
IMTP(D)2.2;
400V for
ITTP(D)2.2/../7.5
0.1
0
*(50Hz)
60 Hz
2920 RPM
*(0.80)
0.82
*(105%)
103%
80%
Pump data
(PASSWORD
required)
Maximum Pressure
[BAR]
Self regulation Check
[ON/OFF]
Maximum pressure limitation
With Check=ON, at the next START
begin the check, to store all electrical
and hydraulic curves of the motor-
pump.
*(0.5 .. 30 bar)
1.0 .. 50 bar
ON/OFF
Absolute Press.:
10 bar
16 bar
Differential:
5 bar
ON
Sensor data
(PASSWORD
required)
MIN [ mA; V]
MAX [ mA; V]
Range [BAR]
N° of transducers
with DP control
MIN: minimum output value pressure
transducer
MAX: maximum output value
pressure transducer
Range: measure range of pressure
transducer
0 .. 16 mA
*(16 .. 22 mA)
4 .. 22 mA
0.1 .. 50.0 bar
4 mA
20 mA
Absolute Press.:
16 bar
Differential:
5 bar
