Electrolux Professional Compass Pro ELD-618 - Eld-665, Eld-685

Installation manual
15
3.1.4 ELD-665, ELD-685
3
A
1
2
C
I
J
P
G
5
4
6
8
H
L
K
N
7
M
O
F
9
10
E
D2
B
D1
11
fig.X01722
1 Operating panel
2 Door opening, ELD-665, ELD-685: ⌀ 435 mm / 17 1/8 inch
3 Detergent container
4 Cold water
5 Hot water
6 Re-used water
7 Drain valve
8 Liquid detergent supply
9 Electrical connection
10 Steam connection
11 Cold water (for detergent container) / Hot water
mm
inch
A B C D1 D2 E F G
ELD-665 830
32 11/
16
1030
40 9/16
1430
56 5/16
470
18 1/2
550
21 5/8
1590
62 5/8
1135
44 11/
16
80
3 1/8
ELD-685 910
35 13/
16
1115
43 7/8
1465
57 11/
16
505
19 7/8
585
22 1/16
1675
65 15/
16
1170
46 1/16
80
3 1/8
mm
inch
H I J K L M N
ELD-665 1330
52 3/8
325
12 13/
16
245
9 5/8
1290
50 13/
16
1205
47 7/16
280
11
105
4 1/8
ELD-685 1365
53 3/4
345
13 9/16
245
9 5/8
1325
52 3/16
1245
49
280
11
105
4 1/8
mm
inch
O P
ELD-665 265
10 7/16
160
6 5/16
ELD-685 210
8 1/4
160
6 5/16
