11.16 Alarm Summary Table
Alarm Description Possible fault Machine status/action Reset
E00
E11
Water fill difficulty during washing
Tap closed or water pressure too low; Drain pipe improperly
positioned; Water fill solenoid valve faulty; Leaks from water circuit on
pressure switch; Pressure switch faulty; Wiring faulty; Main PCB faulty.
Cycle is paused with door locked START/RESET
E13 Water leaks
Drain pipe improperly positioned; Water pressure too low;
Water fill solenoid valve faulty; Water circuit on pressure switch is
leaking/clogged; Pressure switch faulty.
Cycle is paused with door locked START/RESET
E21
Drain difficulty during washing
Drain pipe kinked/clogged/improperly positioned; Drain filter
clogged/dirty; Wiring faulty; Pressure switch faulty; Drain pump rotor
blocked; Drain pump faulty; Main PCB faulty.
Cycle paused
(after 2 attempts)
START
ON/OFF
RESET
E23
Faulty triac for drain pump Wiring faulty; Drain pump faulty; Main PCB faulty.
Safety drain cycle - Cycle stops with
door open.
RESET
E24
Malfunction in sensing circuit on
triac for drain pump
Main circuit board faulty.
Safety drain cycle - Cycle stops with
door unlocked
RESET
E31
Malfunction in electronic pressure
switch circuit
Wiring; Electronic pressure switch; Main PCB. Cycle stops with door locked RESET
E32
Calibration error of the electronic
pressure switch
Drain pipe kinked/clogged/improperly positioned; Solenoid valve
faulty; Drain filter clogged/dirty; Drain pump faulty; Leaks from
pressure switch hydraulic circuit; Pressure switch faulty;
Wiring; main PCB.
Cycle paused START/RESET
E35 Overflow
Water fill solenoid valve faulty; Leaks from water circuit on pressure
switch; Wiring faulty; Pressure switch faulty; Main PCB faulty.
Cycle interrupted. Safety drain cycle.
Drain pump continues to operate (5 min.
on, then 5 min. off. etc.)
RESET
E38
Internal pressure chamber is clogged
(water level does not change for at
least 30 sec. of drum rotation)
Motor belt broken; Water circuit on pressure switch clogged. Heating phase is skipped RESET
E41
Door open
Check whether the door is closed properly;
Wiring faulty; Door safety interlock faulty;
Main circuit board faulty.
Cycle paused START/RESET
E42 Problems with door lock
Wiring faulty; Door safety interlock faulty;
Electrical current leak between heating element and ground; Main
PCB faulty.
Cycle paused START/RESET
E43
Faulty triac supplying power to door
delay system
Wiring faulty; Door safety interlock faulty;
Main circuit board faulty.
(Safety drain cycle)
Cycle blocked
RESET
E44
Faulty sensing by door delay system Main circuit board faulty.
(Safety drain cycle)
Cycle blocked
RESET
