2010 dmm 76/96 599 73 68-54
13.2.2 Solenoid valve
Remove the worktop (see relevant paragraph).
Disconnect the connectors.
Pull out the pipes which connect the solenoid valve to the detergent dispenser.
Unscrew the water fill pipe from the solenoid valve.
Push the two retainers indicated by the arrows towards the inside of the
appliance. At the same time, turn the solenoid valve to remove it.
13.2.3 Control panel
Remove the worktop (see relevant paragraph).
Pull out the detergent dispenser and at the same time press the tab that locks it
in place.
Loosen the screws that attach the control panel to the detergent dispenser.
