WINDOW INSTALLATION INSTRUCTIONS
Parts Insluded
6. Top mounting rail
seal strip
3. Accordion panel
4. Top mounting rail
7. Foam top
window gasket
5. Window sash seat
1. Sill support
13. Connection bar
2. Bottom mounting rail
8. Type A (4) 9. Type B (9) 10. Type C (8)
11. Nut (2)
12. Bolt (2)
10
Fig. 8
