Page 47 RESI219
TO ACCESS THE FREEZER & FOOD COMPARTMENT SENSORS
The Freezer Sensor is located on the left hand side freezer compartment wall.
The Food Compartment Sensor is located on the right hand side of the rear liner above
the top crisper.
Remove the two screws securing the housing. The sensor is part of the cabinet harness.
TO REMOVE ICE TRAY INLET TUBE
Remove the supply tube from the inlet tube. Turn the inlet tube anti clockwise to disengage
it from the securing tab. Pull upward to remove.
