Alarms signalling icon
A pop up window appears on the display to show the alarm in
progress. The icon remain visible until the problem is
resolved.
Information
An information message communicates if something is wrong,
if a procedure is completed or should be repeated and so on.
F.4 Drawers area
The drawers are an expansion located inside several environ-
ments of the menu and contains options and functions.
UPPER DRAWER
• This drawer allows to navigate into the main menu.
– Upper drawer opening:
– Moving between pages:
Touch the arrows in the scrolling area;
– Upper drawer closing:
Touch button to close the drawer.
LOWER DRAWER
• This drawer allows to access to further options, accessories
and advanced features.
– Lower drawer opening:
– Lower drawer closing
LOWER DRAWER functions – Utilities
This drawer contains further settings, accessory management
and advanced features. Its composition depends on the setting
parameters and on the phase cycle.
Fan speed
• Touch this icon to set the speed of the fan from 1 to 7 levels.
• Touch icon to close and enable the setting.
• To disable this function operate on / icons.
Water injection into cavity (available only for the
convection cooking cycle)
Touch this icon to increase the humidity level in the cavity at the
beginning of the cooking phase.
• Set the duration of the water injection (from 10 seconds to 30
minutes).
• Touch icon to close and enable the setting.
• To disable this function operate on / icons.
