Electrolux Compass Pro WS6-8 - Connections

Installation manual
13
3.3 Connections
WS6–8 WS6–9 WS6–11 WS6–14 WS6–20 WS6–28 WS6–35
Water valves DN
BSP
20
3/4”
20
3/4”
20
3/4”
20
3/4”
20
3/4”
20
3/4”
20
3/4”
Recommended water pressure kPa 200–600 200–600 200–600 200–600 200–600 200–600 200–600
Continuous operating pressure kPa 50–800 50–800 50–800 50–800 50–800 50–800 50–800
Capacity at 300 kPa l/min 20 20 20 20 30 60 60
Drain valve
⌀ outer
mm
75 75 75 75 75 75 75
Draining capacity l/min 170 170 170 170 170 170 170
Steam valve connection DN
BSP
15
1/2”
15
1/2”
15
1/2”
15
1/2”
15
1/2”
15
1/2”
15
1/2”
Recommended steam
pressure
kPa 300–600 300–600 300–600 300–600 300–600 300–600 300–600
Functioning limits for steam
valve
kPa 50–800 50–800 50–800 50–800 50–800 50–800 50–800
* There are NH and DN (BSP) threaded on the valves of this machine, please refer to Water connection section for
further information.
