Introduction & Purpose
Q&CI Technical Support – RA
Chapter 1
CONTENTS:
Introduction & Purpose Chapter 1
User Interface – Introduction Chapter 2
EDW 7100 Chapter 3.1
EDW 7200 Chapter 3.2
EDW 7300 Chapter 3.3
Purpose:
To describe all the Service Mode functions for the User Interfaces included
on this Service Manual
Abbreviations, Acronyms and Definitions
RTA Remaining time adaptation
MCF Machine Configuration File
NTC
PB100
DIVA2
MCB
ADO
Negative Temperature Coefficient resistor
New platform for dual BLDC machines (Global hydraulic)
Platform with single BLDC control in separate unit (MCB)
Motor Control Board (DIVA2)
Auto Door Opener
Document Revisions
Revision Date Description Author
V0.0 05/2019 Document creation Rui Almeida
Electrical appliances must be serviced only
by qualified Service Engineers.
Always use proper safety equipment.
Always remove the plug from the power
socket before touching internal components.
