5
MOUNT THE M ICROWAVE
OVEN (cont.)
Installat ion Instruct ions
8
7
Tighten the outer two screws to the top of the
microwave oven. (While tightening screws, hold
the microwave oven in place against the wall and
the top cabinet.)
Insert 2 self-aligning screws
through outer top cabinet
holes. Turn two full turns on
each screw.
Install grease filters. See the Owner’s Manual
packed with the microwave.
C4.
3
2
1
#1 Phillips screwdriver.
Open the door.
Remove the grille.
Pull the grille straight off.
NOTE: The charcoal filter is factory installed in
recirculating models. Follow these steps to replace a
filter or to install a filter after converting a vented
model to recirculating operation.
Remove screws on top of grille using a
C5.
INSTALLING OR CHANGE
THE CHARCOAL FILTER
6
4
Replace the grille and the screws.
Close the doo r.
5
Install the charcoal lter: Lay the lter on the back
of the grille with the black mesh face upper.
6
Tighten center
screw completely.
Charcoal filter
Tabs
To Next Page
