ERF2000 Functions of the electronic boards Rev. 01 7/30
ref Model Not mounted optional components
1
2 GTH4
3 GTH2; GTH4;
4 DME MA
5 266 REX
6 316/346 ZS
7 316/346
8 MA-KSV20042 VALVE
9 MA-KSV18048 VALVE
10 ADAPTIVE COOLER AEG FI room NTC sensor; DL2; SW5;
11 ADAPTIVE COOLER QUELLE FI room NTC sensor; DL2; SW5;
12 4 STARS BI AEG -
13 4 STARS BI QUELLE -
14 1780 BI AEG room NTC sensor;
15 1780 BI QUELLE room NTC sensor; DL7; SW2; SW7; DL1; SW3; DL2;
16 1780 BI ELECTROLUX room NTC sensor;
17 COMBI 2C QUELLE MA room NTC sensor; SW5; SW9; LD3; LD6; LD1A; LD3A; LD6A; LD7A;
18 266 REX room NTC sensor; SW1; LD1A; LD3A; LD6A; LD7A;
19 316/346 REX ZS room NTC sensor; SW1; LD1A; LD3A; LD6A; LD7A;
20 ZS QUELLE 186/156 FZ room NTC sensor; SW1; SW10; LD7; LD4A; LD6A; LD7A;
21 ZS QUELLE226 FZ room NTC sensor SW1; SW10; LD7; LD4A; LD6A; LD7A;
22 MA FZ STD QUELLE room NTC sensor; SW10; LD7; LD4A; LD6A; LD7A;
23 MA FZ MAXI QUELLE room NTC sensor; SW10; LD7; LD4A; LD6A; LD7A;
24 296 C ZAN room NTC sensor; SW1; LD4A; LD7; SW10; LD6A; LD7A;
25 MA ELUX FSX14532 room NTC sensor; LD4A; LD6A; LD7A;
26 MA ELUX FSX16532 FSX18532 room NTC sensor; LD4A; LD6A; LD7A;
27 MA QUELLE FSX16532 FSX18532 room NTC sensor; SW10; LD7; LD4A; LD6A; LD7A;
28 MA AEG FSX14532 room NTC sensor; LD7; LD4B; LD6/LD6B;
29 MA AEG FSX16532 FSX18532 room NTC sensor; LD7; LD4B; LD6/LD6B;
30 MA ZAN COOLER STD room NTC sensor; SW10; LD4A; LD7; LD6A; LD7A;
31 MA ZAN FREEZER STD room NTC sensor; LD4A; LD6A; LD7A;
32 156 FZ room NTC sensor; SW1;
33 186 FZ room NTC sensor; SW1;
34 226 FZ room NTC sensor; SW1;
35 FZ MAXI MA room NTC sensor;
36 FZ STD MA room NTC sensor;
