Electrolux EW30IS65JS - Cooktop Controls and Operation; Induction Cooktop Pad Functions

14
Feature Overview
COOKTOP CONTROL PAD FUNCTIONS
38
39
40
41
42
43 45
44 46
ON / OFF Pad- Used to toggle ON and OFF the associated induction element.
HI + Pad- Used to select the “Power Boost” temperature or raise the temperature
currently displayed.
MED Pad- Used to select the medium temperature.
LO - - Used to select the lowest temperature or lower the temperature currently
displayed.
Pan Detection Indicator Ring- Will light up when a pan made of magnetic material
is placed in a cooking zone.
Left Front Zone Controls and Display- Used to set the left front cooking zone
power levels.
Left Rear Zone Controls and Display- Used to set the left rear cooking zone
power levels.
Right Front Zone Controls and Display- Used to set the right front cooking zone
power levels.
Right Rear Zone Controls and Display- Used to set the right rear cooking zone
power levels.
38
39
40
41
42
43
44
45
46
