37
Setting Up on a Concrete Pedestal
When setting up the washing machine on a concrete
pedestal, it is essential for safety reasons to fit stand
plates in which the washing machine is then
adjusted. The stand plates are available from the
Customer Service Centre.
Setting Up on a Vibrating floor
In the case of vibrating floors, especially wooden
beam floors with flexible boards, securely screw a
water-resistant wooden panel at least 15mm thick
onto at least 2 of the floor beams. If possible, set up
the unit in a corner of the room where the wooden
floor is best firmly installed and is therefore least
likely to be susceptible to vibrations.
Compensate for Floor Unevenness
3
Automatic Adjustment Foot: Your washing
machine's rear left foot is of a spring leg
design. This guarantees good stability of the
unit, even at high spinning speeds.
If the washing machine still does not stand firmly
enough during spinning, proceed as follows:
1. Adjust the three adjustment feet to the setpoint
10mm. To do this, use the supplied special span-
ner to remove the transport safeguard.
If the automatic adjustment foot still does not reach
the floor:
2. Manually extend the automatic adjustment foot
(rear left) by the necessary amount.
3. If necessary, check the setting with a spirit level.
Attention! Never use wood, card or similar underlays
to compensate for minor floor unevenness. Always
use the adjustable screw-type feet of the machine.
