Electrolux FOM 71 CLS - Procedure for Changing Parameters in SETTINGS 1

7:2
Adjustment of temperature, speed and water
NOTE: It is advisable that authorized technicians from Electrolux
Laundry Systems are contacted before any change is made.
Procedure for changing parameters in SETTINGS 1
Electrical installation must be carried out by an authorized personnel
• TurnmainswitchattherearofthemachinetoOFF.
• Disconnectthemachinefromthemainpower.
• Unscrewthelidtotherearelectricalconnectionbox(4screws)andre-
move the lid.
• Removethemainswitchknobfromthelidandplacetheknobinthe
main switch again.
• Reconnectthemachinetomainpowerandturnthemainpowerswitch
to ON.
• SelectMENUindisplay.
• GodowntoSETTINGS1.
• Selectandchangethedesiredparameter.Foralistofavailableparame-
ters, see Table 1.
• Onceallchangeshavebeenmade,gotoREADY(lastlineinSettings1).
• Insertashort-circuitjumperoverthetwopinstotherightinconnection
X80 on the A21 board in rear connection box. (The board to the right
facing rear). The location of X80 is shown in fig. 1. The jumper is stored
on one of the pins in the X80 connector.
• PressSELECTonthefrontpanelandreadindisplaythatthechanges
have been loaded into the CPU.
• Disconnectthejumper.Replacethejumperononlyonepin.
• TurnmainswitchtoOFFanddisconnectmainpower.
• Re-tthemainswitchknobintherearconnectionboxlidandre-tthe
lid on the machine (knob in the OFF position).
• ConnectthemachinetomainpowerandturnmainswitchtotheON
position.
