Q&CI - Technical Support 16 599 844 - 908 Rev. 01
3.8.1 Display “Progress LED bar”
The progress LED bar consists of ten segments. Each segment consists of a red LED and a white LED which can be illuminated and dimmed
separately.
The progress LED bar has various functions:
- Temperature state (cavity, set temperature)
- Running time (Microwave, cleaning)
- Highlighting error messages
- etc.
Heating up phase
Cooling down phase
Microwave: The remaining runtime is displayed in red.
Threshold >60°C
