Electrolux OS201E Series - Appendix G: Gas Calibrations

Electrolux Professional S.p.A.
Ovens Platform Customer Support
Technical Training & Service
AOS OVENS - Service Manual
(595889300 – ENG)
APPENDIX G – GAS CALIBRATIONS
AOS061G
CAVITY BURNER
Parameters
GAS Injector Aerator
OFFSET
(hPa)
StcAhAcAFucA
G20 6.50 Yellow - 0.20 35 30 60
G25 7.80 Yellow - 0.20 35 30 60
G30 5.30 Yellow - 0.25 40 28 43
LPG 5.30 Yellow - 0.13 40 28 43
BOILER BURNER
Parameters
GAS Injector Aerator
OFFSET
(hPa)
Stbo hAbo Fubo
G20 6.50 Yellow - 0.20 55 35 78
G25 7.80 Yellow - 0.20 55 35 78
G30 5.30 Yellow - 0.28 55 36 66
LPG 5.30 Yellow - 0.18 55 36 66
File: AOS service manual (ENG).008 ©Copyright 2002 by Electrolux Professional P.32/40
