Electrolux Professional S.p.A.
Ovens Platform Customer Support
Technical Training & Service
AOS OVENS - Service Manual
(595889300 – ENG)
AOS102G
CAVITY BURNER
Parameters
GAS Injector Aerator
OFFSET
(hPa)
StcA hAcA FucA
G20 7.00 Red - 0.17÷ - 0.10 45 43 100
G25 8.50 Red - 0.17÷ - 0.10 45 43 100
G30 5.70 Red - 0.25÷ - 0.18 60 43 100
LPG 5.70 Red - 0.10÷ - 0.02 60 43 100
BOILER BURNER
Parameters
GAS Injector Aerator
OFFSET
(hPa)
Stbo hAbo Fubo
G20 7.00 Red 0 43 50 100
G25 8.50 Red 0 43 50 100
G30 5.70 Red - 0.15 35 45 78
LPG 5.70 Red 0 35 45 78
LPG conversion for cavity burner for AOS102G
For LPG installations, put the ø 25 flow reducer flange between cavity burner fan and cavity burner. Change
the PWM parameters.
Then change the injector with the 5.70 one and calibrate the offset in the range - 0.10 ÷ - 0.02 hPa so as to
eliminate possible whistles/noise. After you have found the best working condition, cool down and verify
ignitions with cold burner.
File: AOS service manual (ENG).008 ©Copyright 2002 by Electrolux Professional P.35/40
