AOS OVENS - Service Manual
(595889300 – ENG)
AOS202G
UPPER CAVITY BURNER
Parameters
GAS Injector Aerator
OFFSET
(hPa)
StcA hAcA FucA
G20 7.00 Red - 0.20 45 43 100
G25 8.00 Red - 0.20 45 43 100
G30 5.70 Red - 0.20 ÷ - 0.15 40 43 95
LPG 5.70 Red - 0.10 ÷ - 0.05 40 43 95
LOWER CAVITY BURNER
Parameters
GAS Injector Aerator
OFFSET
(hPa)
StcA hAcA FucA
G20 7.00 Red - 0.20 45 43 100
G25 8.00 Red - 0.20 45 43 100
G30 5.70 Red - 0.25 ÷ - 0.20 40 43 95
LPG 5.70 Red - 0.15 ÷ - 0.10 40 43 95
UPPER BOILER BURNER
Parameters
GAS Injector Aerator
OFFSET
(hPa)
Stbo hAbo Fubo
G20 7.50 Red - 0.05 ÷ 0.00 40 50 100
G25 8.50 Red - 0.05 ÷ 0.00 40 50 100
LPG2/G30 5.80 Red - 0.07 ÷ - 0.02 40 45 90
LPG1 6.00 Red - 0.07 ÷ - 0.02 40 45 90
LOWER BOILER BURNER
Parameters
GAS Injector Aerator
OFFSET
(hPa)
Stbo hAbo Fubo
G20 7.50 Red - 0.05÷0.00 40 50 100
G25 8.50 Red - 0.05÷0.00 40 50 100
LPG2/G30 5.80 Red - 0.07÷- 0.02 40 45 90
LPG1 6.00 Red - 0.07÷- 0.02 40 45 90
