R600a NOFROST REFRIGERATORS
14/22
6.4 COMPRESSOR COMPARTMENT:
At the back of the appliance there is the timer H;
by using a screwdriver it is possible to rotate the shaft
cam manually, only clockwise, to switch the 3-4 and
3-2 contacts switch.
TIME “A” TIME “B”
14 h 26 ‘ 36 ‘
