20
DAMPER MOTOR
EVAP. FAN MOTOR
REFRIGERATOR
CONTROL
1
2
3
FRONT SWITCH
BACK SWITCH
A.D.C.
2
1
E1
E2
TO DEFROST HEATER
N
L1
E6
E8
E5
TO DEFROST THERMOSTAT
E9
E7
TO FOOD COMPARTMENT LIGHT SWITCH
E3
TO COMPRESSOR
E4
FREEZER CONTROL
FIGURE 17
FOOD COMPARTMENT CONTROL IN OFF POSITION
DAMPER CLOSED ALL THE WAY
NO
NC
C
C
NO
NC
NOTE: SWITCHES WILL CLOSE AND
OPEN ONE AT A TIME TO PREVENT
STALLING IN A HALF OPEN POSITION
AS A RESULT OF A POWER OUTAGE
A.D.C. ADAPTIVE
DEFROST CONTROL
DAMPER MOTOR
EVAP. FAN MOTOR
REFRIGERATOR
CONTROL
1
2
3
FRONT SWITCH
BACK SWITCH
A.D.C.
21
E1
E2
TO DEFROST HEATER
N
L1
E6
E8
E5
TO DEFROST THERMOSTAT
E9
E7
TO FOOD COMPARTMENT LIGHT SWITCH
E3
TO COMPRESSOR
E4
FREEZER CONTROL
FIGURE 16
FOOD COMPARTMENT CONTROL IS SATISFIED
DAMPER MOTOR STARTS RUNNING TO CLOSE DAMPER
NO
NO
NC
NC
C
C
NOTE: SWITCHES WILL CLOSE AND
OPEN ONE AT A TIME TO PREVENT
STALLING IN A HALF OPEN POSITION
AS A RESULT OF A POWER OUTAGE
A.D.C. ADAPTIVE
DEFROST CONTROL
