Maintenance Manual
11
4.4 Air intake, fan house and fan motor
At regular basis, check that the air intake on the front of the machine is not clogged by lint and dust or otherwise
blocked.
Disconnect the power to the machine.
Demount the the back panel.
Remove the screws to the filter (A) and pull out the filter (B).
Clean the fan house from the front of the machine with a vacuum cleaner.
Clean the motor both from the front and back of the machine with a vacuum cleaner.
Be careful not to damage the parts.
fig.8016A
Push the filter (B) back into position and remount the filter (A).
Remount the back panel.
