Electrolux TD60 - E15 No Vacuum Detected Analysis

56
Troubleshooting
E 15 - No vacuum detected
Error description
The vacuum/pressure switch does not close within 12 seconds of the fan starting.
Error analysis
E – 15
Check the motor’s
connection and phase
order.
NO
YES
Go to step 3.
2. Does the fan motor
rotate in the correct
direction?
Resetting
Resetting is done by opening/closing the dryer loading door and pressing the start
button
NO
YES
YES
Replace PCB
3. Is the measuring
over 100V AC
between P2-5 and
P2-2 within 12
seconds when dryer
is not operating.
NO
See check list.
Correct airflow problem
as appropriate.
1 Is the
underpressure in the
drum compartment
below 90Pa.
Go to step 2.
Replace the air pressure
switch.
