Electrolux TT500 - Gas Pressure and Adjustment Tables

487 18 39 01 - 300/500/750 - GB
Installation - gas heating
Gas type Gas pressure Ø
Inlet Nozzle
1
MJ/m3 mbar mbar mm
LPG 126.4 30 30 2.2
GNH 37.4 18 10.5 3.8
GNL 33.6 18 15.2 3.8
LPG 126.4 30 30 3.2
GNH 37.4 18 8 5.6
GNL 33.6 18 8 6.2
LPG 126.4 30 30 3.8
GNH 37.4 18 9.5 6.5
GNL 33.6 18 14 6.5
Nozzle pressure
(Measuring branch)
2
Tumble
type
Heat effect
500/50
750/75
650
40
57
kW
300/30
21
Tables of pressure and adjustments only for english speaking countries
except: Great Britan, Eire, Australia and New Zealand.
Upper calorific
value
Gas installation
Gas type Gas pressure Ø
Inlet Nozzle
1
MJ/m3 mbar mbar mm
LPG 125.81 28/37 28/37 2.2
GNH 37.78 20 10.5 3.8
LPG 125.81 28/37 28/37 3.2
GNH 37.78 20 8 5.6
LPG 125.81 28/37 28/37 3.8
GNH 37.78 20 9.5 6.5
Nozzle pressure
(Measuring branch)
2
Tumble
type
Heat effect
500/50
750/75
650
40
57
kW
300/30
21
Tables of pressure and adjustments
only for: Great Britan and Eire
Upper calorific
value
