Electrolux Unic Tango Ace - Page 28

28
Tango 0060 5-2021
Lift Turntable out
Caution, it may be hot!
Remove Nut and Bearing
assembly
Remove locking collar
Remove 22 mm adjust-
ment nut
Do not damage position
sensors when removing
Turntable!
Rotate Turntable so the
tabs are not inside the
sensor slots
Loosen 2.5 mm turntable lock
screws
(Rotate shaft rst if needed)
Pry the top bearing race out if
it stayed on the shaft
!
!
Tango Turntable Service
Remove Turntable
4
5
3
2
1
8
7
6
