27
Tango 0060 5-2021
Lift both side shrouds
straight up
Remove Ejector bell as-
sembly
Lift Turntable cover o󰀨
Clean cover with soapy water
Remove Turntable drive-
shaft
Remove the piston at this time to
allow better cleaning if needed.
See Piston Exchange Instructions
Remove side shrouds
Loosen 7 mm bolt rst
Do Not remove bolt
Lift lower coupling from
gearbox
Remove Co󰀨ee Funnel
Press spring latch in while
pulling funnel straight out
Remove the three 6 mm
Allen screws from the
turntable cover
Tango Turntable Service
Access Turntable
14
15
13
12
11
17
16
9
10
