29
ADDRESSES 132 – 139: KEYPAD PARAMETERS
The following addresses offer options for the configuration of each keypad.
132 First Digit: Backlight and Buzzer Operation for Keypad # 1
Select the backlight and buzzer options from the following table.
First digit value:
Buzzer Backlight Value
On after keystroke for 1 minute 0
On for opening windows 1
Audible On for closing windows 2
On for opening/closing windows 3
On at all times 4
On after keystroke for 1 minute 8
On for opening windows 9
Silent On for closing windows A
On for opening/closing windows B
On at all times C
Second Digit: Keypad Supervision, System Operation and Display for keypad #1
In partitioned systems, each keypad is associated with a specific sub-system and can be
programmed to display only its own sub-system or all the sub-systems. Keypad supervision is
selected at this address and on the keypad itself - see 2.2: Mounting the Keypad.
Second digit value:
Supervision
Display
System
Operate
System
Value Supervision
Display
System
Operate
System
Value
1 1 0 1 1 8
2 2 1 2 2 9
3 3 2 3 3 A
No 4 4 3 Yes 4 4 B
1 4 1 C
All 2 5 All 2 D
3 6 3 E
4 7 4 F
133 Same as above keypad #2
134 Same as above keypad #3
135 Same as above keypad #4
136 Same as above keypad #5
137 Same as above keypad #6
138 Same as above keypad #7
139 Same as above keypad #8
ADDRESSES 140 - 179: TELEPHONE NUMBERS
Consecutive addresses are used to enter telephone numbers up to 16 digits. Indicate the end of the
telephone number with the hex digit F. To enter a 3 second pause enter C, for a 7 second pause enter D,
to switch from pulse to tone dialing, enter E. Other telephone data and parameters are entered at later
addresses.
Note: The emergency telephone numbers shall not be set or programmed to place a call to a
police station that has not been specifically assigned by that police station for such service.
140-147 Telephone #1(primary)
148-155 Telephone #2(backup)
156-163 Telephone #3
164-171 Telephone #4 Note: Usually used with the Follow-me feature (SELECT, 4, 6).
172-179 Telephone number for Remote Programmer Callback.
The Remote Programmer Callback telephone number is programmed using the same method
as telephone numbers 1 - 4.
