Elektro-Automatik EA-PSI 800R Series User Manual

18
© 2006, Elektro-Automatik GmbH & Co. KG
Irrtümer und Änderungen vorbehalten
EN
© 2009, Elektro-Automatik GmbH & Co. KG
Handling the device
Technical specications
PSI 880-40R PSI 880-60R PSI 8360-10R PSI 8360-15R
Mains input
Input voltage 90….264V 90….264V 90….264V 90….264V
Frequency 45….65Hz 45….65Hz 45….65Hz 45….65Hz
Power factor correction >0.99 >0.99 >0.99 >0.99
Input current at 230V and full load approx. 4.8A approx. 7.5A approx. 4.8A approx. 7.5A
Input current at 100V and full load approx. 11.4A approx. 11.4A approx. 11.4A approx. 11.4A
Fuse 16A 16A 16A 16A
Output - Voltage
Nominal voltage U
Nom
80V 80V 360V 360V
Accuracy <0.1% <0.1% <0.1% <0.1%
Stability at 10-90% load <0.05% <0.05% <0.05% <0.05%
Stability at ±10% ¨ U
In
<0.02% <0.02% <0.02% <0.02%
Ripple
<70mV
PP
<70mV
PP
<100mV
PP
<100mV
PP
Regulation 10-100% load <2ms <2ms <2ms <2ms
Output - Current
Nominal current 40A 60A 10A 15A
Accuracy <0.1% <0.1% <0.1% <0.1%
Stability at 0-100% ¨ U
Out
<0.15% <0.15% <0.15% <0.15%
Stability at ±10% ¨ U
In
<0.05% <0.05% <0.05% <0.05%
Ripple
<100mA
PP
<100mA
PP
<15mA
PP
<15mA
PP
Output - Power
Nominal power 1000W 1500W 1000W 1500W
Nominal power at U
In
<150V
1000W 1000W 1000W 1000W
Miscellaneous
Operation temperature 0….40°C 0….40°C 0….40°C 0….40°C
Storage temperature -20….70°C -20….70°C -20….70°C -20….70°C
Humidity <80% <80% <80% <80%
Dimensions (WxHxD) 90x360x240mm 90x360x240mm 90x360x240mm 90x360x240mm
Weight 8.9kg 9.2kg 8.9kg 9.2kg
Article No. 21540407 21540408 21540409 21540410
Safety
EMC standards
Overvoltage category
Protection class
EN 60950
EN 61204, EN 55022 Class B
Class II
Class I
