7
Remote control
1. Input selector buttons
Press these buttons to select an analog inputs.
2.A/B/C/D button
Press the button to select a group of preset stations.
3.BASS Parameter selector button
Press the button to select bass tone, then press button
"8" to adjust the low-frequency response.
4.TREBLE Parameter selector button
Press the button to select treble tone, then press button
"8" to adjust the high-frequency response.
5.BALANCE Parameter selector button
Press the button to select balance, then press button
"8" to adjust the balance between left and right.
6.MUTE
Mute the sound. Press again comeback to the
previous volume level.
7.SLEEP button
Press the button "7" repeatedly to turn the sleep timer
on or off, and set the sleep time(10-20-30-40-50-60-
70-80-90mins).
8.PARAMETER selected and MASTER VOLUME
adjustment buttons
To adjust parameter selected or main volume.
9.Standby button
Press this button to set the unit into the standby mode.
Press again to turn on the power.
10.FM/AM band switches button
Press the button to select input source as tuner then
select the reception band between FM and AM.
11.Number 1-8 button
Press the button to look for preset station number on
the tuning status.
12.MEMORY button
Use the button to enter a station to memory.
13.TUNER automatic tuning button
Hold down the button 3 seconds, all stations
are browsed and stored automatically.
(AM/FM is detached)
14.TUNING SCAN+,SCAN- buttons
Press the SCAN+ slide the tune to higher
frequency.
Press the SCAN- slide the tune to lower
frequency.
10
1
2
3
4
5
6
7
8
9
12
13
14
11
RECEIVER CONTROLS & FUNCTIONS
