19
DVD MINI COMBINATION SYSTEM
Specification
Power supply AC230V 10%,50Hz~60Hz
Power consumption 100VA
Working Temperature -10 ~ +40
0
Ñ
environment Relative humidity 5%~90%
Disc output TV System PAL/NTSC
Output level 1V (P-P 75 Ω NEGATIVE
SYUCHRONISM)
Output level 1.0~2.2V (rms 1 KHz/0 dB)
Frequency Reponse 20 Hz~20 KHz
S/N A weight > 80 dB (1 KHz)
Frequency Range ≥ 70 dB (1 KHz)
THD+NOISE ≤ 60 dB (1 KHz)
WOW FLUTTER Below the limit of apparatus
measure
Tuner AM frequency Range (522 1629) KHz (step = 9 kHz);
(530 1710) KHz (step = 10 kHz)
S/N(A weight) 46 dB
FM band Range 64 MHz~108 MHz
S/N(STEREO) 40dB
Bass control ± 7 dB (200 KHz)
Treble control ± 7 dB (10 KHz)
Power output (Max) 25 W + 25 W
Frequency reponse ± 1.5 dB (20 Hz~20 KHz)
