Elenberg MC-4080 - Device Panel Overview; Front Panel Controls and Indicators; Rear Panel Ports and Connections

6
Replace the same fuse after pulling out the power pulg
Panel
FRONT PANEL:
w
1. POWER
2. AM/FM/V-MODE
3. AUTO/A-MODE
4. MEMORY/AUDIO
5. MO/ST/SUBTITLE
6. RADIO/SKIP
7. TUNING/SEARCH
8. OPEN/CLOSE
9. PLAY/PAUSE
10. STOP
11. SOURCE SELECT
12.MICROPHONE
13. MIC VOL
14. ECHO
15. VOLUME
REAR PANEL:
1. VIDEO
2. S-VIDEO
3. L-CHANLE
4. R-CHANLE
5. COAXIAL OUT
6. OPTICAL OUT
7. COMPONENT V/Pr, U/Pb, Y
8. VGA
9. AM/FM ANTENNA
10. LINE1, 2 INPUT
11. FUSE
12.SCART
NOTES NO VGA terminad for some types of machine
