Elenco Electronics Snap Circuits Light - Parts List

-2-
Important: If any parts are missing or damaged, DO NOT RETURN TO RETAILER. Call toll-free (800) 533-2441 or e-mail us at:
help@elenco.com. Customer Service • 150 Carpenter Ave. • Wheeling, IL 60090 U.S.A.
Parts List (Colors and styles may vary) Symbols and Numbers (page 1)
Qty. ID Name Symbol Part # Qty. ID Name Symbol Part #
 1
Base Grid
(11.0” x 7.7”)
6SCBG
 1
White Light Emitting
Diode (LED)
6SCD6
 3
1-Snap Wire 6SC01
 1
Color Light Emitting
Diode (LED)
6SCD8
 6
2-Snap Wire 6SC02
 1
Jumper Wire (black) 6SCJ1
 3
3-Snap Wire 6SC03
 1
Jumper Wire (red) 6SCJ2
 1
4-Snap Wire 6SC04
 1
Motor 6SCM1
 1
5-Snap Wire 6SC05
 1
Spare Motor Top 6SCM1T
 1
6-Snap Wire 6SC06
 1
Glow Fan Blade 6SCM1FG
 2
Battery Holder - uses
two (2) 1.5V type “AA”
(not Included)
6SCB1
 1
Disc Holder 6SCM1DH
 1
0.1µF Capacitor
6SCC2
 1
Set of Disc Cutouts
(6 pcs. / set)
6SCM1DS
 1
100µF Capacitor
6SCC4
 1
PNP Transistor 6SCQ1
 1
Red Light Emitting
Diode (LED)
6SCD1
 1
NPN Transistor 6SCQ2
You may order additional / replacement parts at our website: www.snapcircuits.net
5
4
3
2
1
Q1
C2
D1
C4
Q2
6
B1
D8
M1
D6
