Elenco Electronics Snap Circuits Light - Parts List (page 2)

-3-
Important: If any parts are missing or damaged, DO NOT RETURN TO RETAILER. Call toll-free (800) 533-2441 or e-mail us at:
help@elenco.com. Customer Service • 150 Carpenter Ave. • Wheeling, IL 60090 U.S.A.
Parts List (Colors and styles may vary) Symbols and Numbers (page 2)
Qty. ID Name Symbol Part # Qty. ID Name Symbol Part #
 1
Phototransistor 6SCQ4
 1
Strobe IC 6SCU23
 1
100Ω Resistor
6SCR1
 1
Infrared Receiver 6SCU24
 1
5.1kΩ Resistor
6SCR3
 1
Fiber Optic Cable 6SCFC
 1
100kΩ Resistor
6SCR5
 1
Fiber Optic Cable
Holder, clear
6SCFCHC
 1
Adjustable Resistor 6SCRV
 1
Fiber Optic Cable
Holder, black
6SCFCHB
 1
Slide Switch 6SCS1
 1
Fiber Optic Tree 6SCFT
 1
Press Switch 6SCS2
 1
Mounting Base
(for fiber optic tree)
6SCFMB
 1
Speaker 6SCSP
 1
Tower LED
Attachment
6SCTOWER
 1
Microphone 6SCX1
 1
Egg LED Attachment 6SCEGG
 1
Color Organ 6SCU22
 1
Prismatic Film 6SCFILM
 1
Stereo Cable 9TLSCST
 1
Red/Green/Blue
Filters Set
6SCFRGB
You may order additional / replacement parts at our website: www.snapcircuits.net
S1
RV
R5
R3
R1
X1
U22
S2
SP
U24
U23
Q4
