2. INSTALLATION
2.
Installation
Remove the unit from its packaging and before attempting any operation, check
that the unit has not been damaged during transport and that all the switches and con-
nectors located on the front and rear panels are serviceable.
Install the unit so that it is accessible from all sides
Ensure that the location of the unit allows for connection to an efficient earthing point
Ensure that the antenna system is suitable
Check that any amplifier to be eventually connected downstream is connected to the
antenna system
Connect the appropriate inputs of the exciter according to the type of operation requi-
red:
the monophonic signal to the XLR connector on the mono board
the stereo signal (low frequency) to the left and right XLR connectors on the stereo
input board
the stereo signal (wide-band) to the MPX connector on the MPX and SCA inputs
board
the RDS signal to one of the two SCA connectors on the MPX and SCA inputs
board
If the RDS board is fitted, the wide-band stereo signal goes directly to the MPX
inputs on the RDS board, so the MPX+RDS output will be connected to the MPX
input on the MPX and SCA inputs board.
Connect the electricity supply cable
Connect the RF output to the input of any amplifier to be used, or to the antenna
system
Switch on the amplifier (if present)
In order to verify that the equipment is functioning correctly, check the values displayed
by the exciter and amplifier displays and instrumentation
