ELGA PC220DIBPM3 - SYSTEM CONFIGURATION

Drain
Example One: 1 x PURELAB
® Chorus 2 (RO/DI) + 15L or 30L Reservoir LA757 / LA578
Example Two: 2 x PURELAB
® Chorus 2 (RO/DI) + 60L Reservoir LA759
Example Three: 4 x PURELAB
® Chorus 2 (RO/DI) + 100L Reservoir LA760
Product
Outlet
Outlet
Outlet
High Flow
Outlet
High Flow
Outlet
Feedwater
Inlet
Drain
Drain
Over ow
Drain Over ow
Product
Outlet
Over ow
J2
4b
4b
J2
J2
Feedwater
Inlet
Feedwater
Inlet
COMMS
Key
Power
Water
Value
Shut Off Tap
Regulator
Position the reservoir
• MAX H. 2000mm above bench
• MAX D 1000mm below bench
Point of Use
Point of Use
SYSTEM CONFIGURATION
Over ow
4b or 4a
Point of Use
