27
TS Series
9.1 Replacement Pump Parts - TS 10
Fig
#
Description Qty Part No.
39 Packing cyl head to valve flat 2 00 04 6210 A
40 Head, dia 100 cylinder 2 00 02 1238 C
41 Washer, spring, rectangular, M12 9 00 09 96 112
42 Nut, hex, M12 9 00 09 4801 2
43 Nipple, 1 1/4” BSP 2 02 04 9718 0
44 Dowety washer 3 00 09 5943 9
45 Connector, Housing 1” BSP 3 02 04 9678 0
46 Ring, packing, 30 x 38 x 2 2 00 05 2194 0
47 Elbow assy 3 02 04 9678 0
48 Piston, dia 70 1 00 02 1213 0
49 Pin, gudgeon, dia 18 1 00 05 1430 0
50 Circlip, internal,B18 2 00 09 17 218
51 Ring, slotted, oil control dia 70 2 00 04 1684 0
52 Ring stepped, compression dia 70 1 00 04 1588 0
53 Ring, plain compression, dia 70 1 00 04 1587 0
54 Gasket Crankcase, dia 70 Cyl. 0.75 1 00 04 1002 A
55 Cylinder, dia 70 1 00 02 10020
56 Washer, spring, rectangular M12 4 00 09 96 112
57 Nut, hex, M12 4 00 09 99 808
58 Stud, M12 x 60 4 00 05 2013 A
59 Valve, finger type, dia 70 cylinder 2 00 03 3096 0
60 Gasket cyl to valve flat 1 00 04 1154 A
61 Flat, valve, dia 70 cylinder 1 00 03 1004 0
62 Bush,centering 2 00 04 2660 0
63 Gasket cyl head to valve flat 1 00 04 1155 A
64 Head, cylinder dia 70 1 00 02 1393 0
65 Washer, spring rectangular, M12 4 00 09 96 112
66 Nut,hex, M12 4 00 09 99 808
67 Dowety washer 1 00 09 5943 7
68 Connector, 7/8'' BSP 1 02 04 9679 0
69 Ring, packing, 30 x 38 x 2 1 00 05 2194 0
70 Adapter assy 1 02 04 9610 0
71 Rivet 4 00 04 6454 A
72 Name Plate 1 02 03 5180 X
Fig
#
Description Qty Part No.
1 Crankcase 1 00 02 1394 0
2 Stud, M12 x 45 12 00 05 1456 A
3 Gasket, free end 1 00 04 3199 0
4 Cover, free end 1 00 03 1809 0
5 Washer 8 00 09 96 108
06 Bolt, hex M8 x 25 8 00 09 06 116
07 Pipe, breather, 1/2'' BSP 1 00 04 1361 B
08 Reducer 1" x 1/2" BSP 1 02 04 9246 0
09 Valve assembly, breather 1 A 020030
10 Ring, packing, 17 x 22 x 2 1 00 05 2186 0
11 Drain plug assembly 1 A020033
12 'O' ring, oil level indicator 1 00 05 2655 0
13 Indicator, oil level, 11/4'' BSP 1 00 05 1344 0
14 Connecting rod and crankshaft
assembly (02 02 2753 0) 1 A020427
Connecting rod with bearing 1 02 03 6255 0
15 Bush, Dia 20 Gudgeon pin 2 00 05 2311 0
16 Needle roller bearing 1 00 09 03 712
17 Bearing, ball single row, 2 00 09 03 361
18 Key, 10 x 8 x 60 1 00 05 1037 0
19 Gasket, fly end 1 00 04 3198 0
20 Seal, oil, B45 x 60 x 12.5 1 00 04 2035 0
21 Cover, fly end 1 00 03 1777 0
22 Washer, spring, rectangular 8 00 09 96 108
23. Bolt, hex, M8 x 25 8 00 09 96 116
24 Piston dia 100 2 02 03 6183 0
25 Pin, gudgeon, dia 20 2 02 03 6183 0
26 Circlip, B20 4 00 09 1722 0
27 Ring, slotted, oil control dia 100 4 00 04 1686 0
28
Ring, stepped compression, dia
100
4 00 04 1757 0
29
Ring, taper plain compression, dia
100
2 00 04 1685 0
30
Gasket Crankcase to dia 100 cyl
0.8
2 00 04 1004 C
31 Cylinder, dia 100 2 00 02 1010 D
32 Washer, spring, rectangular, M12 8 00 09 9611 2
33 Nut, hex M12 8
00 09 48 01
2
34 a) Stud, M12 x 86 6 00 04 7004 A
b) Stud, M12 x 96 2 00 05 1450 0
35 Gasket cylinder to valve flat 2 00 04 1156 A
36 Valve finger 8 00 03 3097 0
37 Flat valve dia 2 00 03 1007 0
38 Bush Centering 2 00 04 2660 0
