31
TS Series
10.1 Replacement Pump Parts - TS 15
Fig
#
Description Qty Part No.
42 Bonded seal 7/8" 1 00 09 5943 7
43 Elbow assy 7/8'' 1 02 04 9679 0
44 Piston assy dia 70
45 Gudgeon pin, dia 18 1 00 04 7775 0
46 Circlip B18
47 Ring slotted, oil control
48 Ring stepped compression 1 02 24 0104 9
49 Ring taper compression
50 Gasket, crankcase to dia 70
cyl .75mm
1 00 04 1002 A
51 Cylinder dia 70 1 00 02 1002 0
52 Valve finger dia 70 2 00 03 3096 0
53 Gasket Cyl to valve flat 1 00 04 1154 A
54 Flat, valve, dia 70 cylinder 1 00 03 1004 0
55 Bush,centering 2 00 04 2660 0
56 Gasket cyl head to valve flat 1 00 04 1155 A
57 Head, cylinder dia 70 1 00 02 1393 0
58 Connector Assembly 1 02 04 9620 0
59 Ring, packing 1 00 05 2186 0
60 Pipe nipple 1 1/4” BSP 2 02 04 9718 0
Fig
#
Description Qty Part No.
1 Crankcase 1 00 02 1394 0
2 Stud, M12 x 45 12 00 05 1456 A
3 Gasket, free end 1 00 04 3199 0
4 Cover, free end 1 00 03 1809 0
5 Washer, spring, rectangular, M8 6 00 09 9610 8
06 Bolt, hex M8 x 25 6 00 09 0611 6
07 Pipe, breather, 1/2'' BSP 1 00 04 1361 B
08 Reducer 1/2'' x 1'' BSP 1 00 04 3655 0
09 Breather Assembly 1 A 020030
10 Drain plug assembly 3/8” 1 A 020033
11 Ring, packing, 3/8” drain plug 1 00 05 2186 0
12 'O' ring, oil level indicator 1 00 05 2655 0
13 Indicator, oil level, 1 1/4'' BSP 1 00 05 1344 0
14 Connecting rod and crankshaft
assembly (02 02 2753 0) 1 A020427
Connecting rod with bearing 1 02 03 6255 0
15 Bush, Dia 20 Gudgeon pin 2 00 05 2311 0
16 Needle roller bearing 1 00 09 03 712
17 Bearing, ball single row, 2 00 09 03 361
18 Key, 10 x 8 x 60 1 00 05 1037 0
19 Gasket, fly end 1 00 04 3198 0
20 Seal, oil, B45 x 60 x 12.5 1 00 04 2035 0
21 Cover, fly end 1 00 03 1777 0
22 Piston assy dia 100
23 Gudgeon pin dia 20 2 02 04 9456 0
24 Circlip B20
25 Ring slotted oil control
26 Ring stepped Compression 2 02 24 3413 9
27 Ring taper plain compression
28 Gasket Crankcase to dia 100 cyl 0.8 2 00 04 1004 C
29 Cylinder, dia 100 2 00 02 1010 A
30 Washer, spring, rectangular, M12 8 00 09 9611 2
31 Nut, hex M12 8 00 09 4801 2
32 a) Stud, M12 x 60 10 00 05 2013 A
b) Stud, M12 x 75 2 00 05 2014 0
33 Gasket, big disc valve, dia 100 cyl. 4 00 05 1921 0
34 Disc valve assembly, dia 100 2 A 02 0042
35 Gkt, small, disc valve dia 100 cyl. 2 00 05 1922 0
36 Cylinder head, dia 100 2 00 02 1239 A
37 Spring washer, M12 12 00 09 9611 2
38 Hex nut M12 12 00 09 4801 2
39 Pipe nipple 2 02 04 9718 0
40 Bonded seal 2 00 09 5943 9
41 Elbow assy 1'' BSP 2 02 04 9678 0
