elgris SMART METER LAN - 7 Technical Specifications

Page 13 of 13
7 Technical specifications
LAN Versions depending
Wert
General
Controller
32 Bits CPU
Interface LAN
10 / 100 Mbit MDIX
Interface RS-485
1200 – 115200 Baud
Rated voltage
Vac
230 / 400
Operating voltage
Vac
100 – 240
Frequency range
Hz
50 / 60
Total own consumption
W
< 1
Current
mA
50 / 100 / 1000 / 5000 (Wandler)
Starting current
mA
1
Accuracy
Voltage
%
0,5
Current
%
0,5
Active power
%
1,0
Apparent power
%
1,0
Reactive power
%
1,0
Power factor (PF)
%
1,0
Active power IEC 62053-22
Klasse 1
Protection degree
II
Environment
IP rating
IP20
Weight
kg
0,2 – 0,3
Dimensions
TE
4
Connection cross section terminals
mm²
< 4
Ambient temperature
°C
-10 – 40
Maximum altitude above sea level
m
1000
