Eliet Maestro - Changing the Engine Oil; Checking or Changing the Spark Plug; Maintenance after 20 Running Hours

11.4 Maintenance after 20 Running Hours
11.4.1 Changing the Engine Oil
Ensure that the engine is parked on a level surface and shut off.
Locate the bolt that is screwed into the crankcase and which is located at the
right side of the engine, at the bottom of the motor bed plate. (See the engine manual.)
Position a 1 litre receptacle beneath the sump first and then remove the oil drain plug.
Allow the oil (± 0.75 l) to drain into the receptacle. The bedplate has a factory hole
which makes for easy draining of the oil from the underside of the motor bed plate.
Refit and tighten the sump plug. Always clean fluid spills using a clean cloth.
Refill the engine with fresh four-stroke oil. ELIET recommend a high quality detergent
oil. SUNOCO DENALUBE SAE 20W50 API SF / CC.
Pour ± 0,75 l of oil into the oil filler plug until it reaches the edge of the filler point.
After filling, clean up any oil that may have been spilled.
Warning:
Too little oil in the engine leads to irrevocable serious damage to
the engine.
11.4.2 Checking or Changing the Spark Plug
With B&S Intek 5.5hp engines,
ELIET recommend the following spark plug.
CHAMPION QC 12 YC
Turn the engine off and let it cool for a while.
For easy access to the spark plug, remove the air cleaner cover.
Disconnect the sparking plug cap from the spark plug.
Clean the area around the spark plug and remove the spark plug from the cylinder
head.
Check with the use of feeler gauges whether the gap between the plug electrodes is
0.8 mm.
If the spark plug is fouled, replace it.
34
English
0,8 mm
