8. Programming process
DIP switch setting
Table 1: DIP switch setting
Dip
1
2
3 y 4
5
6
Dip - interruptor Función SET
Soft start mode
Non-soft start mode
N.C. Stroke limit
N.O. Stroke limit
Función de cierre automáitco está desactivada
Auto close time is about 3 sec.
Auto close time is about 10 sec
Auto close time is about 30 sec.
The motor is in the correct installation position
The motor is installed in the left position.(Change the
engine direction).
External button of K is only for OPEN mode
