PROCEDURE FOR INSTALLATION
Step 3: Position the Miracle 1 horizontally level on the closed gate, where desired. For strength purposes, the
front steel bracket must be attached in an area that can withstand heavy forces. Additional reinforcement steel
plates may be necessary for mounting.
Step 4: Position and level the operator brackets and reinforcement plates. (See next page). Tack weld brackets
and plates in position.
Step 1: Remove the 4 screws and lift the
operator cover off.
Step 2: Release the mechanical lock by turning the
key to the horizontal position.
If using a gate crossbar, weld bar across all pickets. Do not weld
the crossbar on a few pickets, or they will bend.
The Miracle 1 can be mounted on top
of the gate frame.
9
Important:
Tack weld the front steel
bracket at the top of the
crossbar, so the operator
will not hit the crossbar
when in motion.
Mounting Instructions
