Elite Miracle-One - Alarm & Maglock Connections

ALARM & MAGLOCK CONNECTIONS
123
2 Orange Wires
Connect for Open Inside
1. Power - for Open Inside
2. Ground
1234
UL Audio Alarm
Connection
Burglar Alarm
Relay Output
1. Common
2. N. O.
UL Audio Alarm Connection
3 and 4 UL Audio Alarm
1
2
2
1 or 3
3
4
Connect for Open Outside
2. Ground
3. Power - for Open Outside
Maglock Connection Alarm Connection
Relay Contact Rating
0.5 A - 125 VAC
1 A - 24 VDC
Use the harness provided with the unit to make your connections to these alarm outputs.
OR
23
