MIRACLE 1 PARTS LIST
MAINTENANCE
This swing gate operator is designed to be very low in maintenance. For intensive duty
installations: (every six months) lubricate the operator fitting plates, lubricate the gate
hinges, and check that electric connections are in good conditions.
Important: Any service must be performed by an authorized service technician.
35
A BT 12 - Backup Battery
A BT MIR - Plastic Rack and 2 Batteries
A POW3 - Transformer (24 VAC)
A SOLAR ADP - DC Solar Power Adapter
O-MIRACLE 1 ARM - Single Miracle 1 Arm
(Complete)
Q006 - Control Board Screws (Set of 3)
Q162 - 1.5 Amp Fuse
Q222 - Control Board (Single Operator)
Q223 - Control Board (Master/Slave)
Q224 - Power Harness (Master/Slave)
Q226 - Power Harness (Single Operator)
Q227P - Plastic Control Board Box (Nuts
and Bolts for Battery Rack)
Q229 - Replacement Key (Operator made
Pre 3/14/99)
Q230 - Steel Bracket Mounting Plates (2)
Q231 - Radio and Accessory Harness
Q232 - Bottom Washer and Nut (for
Traveler Carriage Bolt)
(Go to Parts Illustrations Page)
Q233 - Bolt, Bushing, Nut (Fits Rear Mount
of Operator)
Q234 - Bracket/Rod
Q239 - Limit Switch Harness (Wires and 4
Limit Switches)
Q240 - Maglock Harness
Q242 - Alarm Harness
Q243 - 8 Amp Fuse
Q257 - Replacement Key (Operator made
Post 3/14/99)
Q258 - 2 Amp Fuse
Q259 - 3 Amp Fuse
Q260 - 15 Amp Fuse (2)
Q262 - Harness-Motor (Operator Cord)
Q300 - Traveler Carriage
Q301 - Arm Cover Set (Top and Bottom,
Aluminum)
Q302 - Arm End Caps (Set)
Q303 - Arm Cover Gaskets (Set)
Q392 - Limit Switch (1)
Q404 - UL Audio Alarm
