Eliwell Coldface EWHT800LX Series User Manual

5 - EN EWHT800LX
English
KEYS
USER INTERFACE
How to modify the SetPoint
• Press and release the SET key. The upper display will show SP1, the lower display will indicate the
current SetPoint value
• Press and release the SET key once more. The upper display will show SP1 blinking
• Use the UP & DOWN keys to adjust the SetPoint value
• Press the ESC key several times (or keep it pressed) to return to the normal display
How to read the probe values
• Press and release the SET key. The upper display will show SP1, the lower display will indicate the
current SetPoint value
• Press and release the DOWN key. If the RTC clock is present, the time will be shown in the lower display
• Press and release the DOWN key once more. The upper display will show Pb1, the lower display
will indicate the value read by the room probe
• Press and release the DOWN key once more to read the value of probe Pb2 and Pb3
• Press the ESC key to return to the normal display
How to modify the Lite Parameters
The Lite parameters are the most useful parameters and are described in this document, in
the section Parameters Table.
1) Press and hold the SET key for 3 seconds until the display shows PAr / Lite
2) Press and release the SET key once more. The upper display will show the rst parameter*, the
lower display will indicate the current parameter value
3) Using the UP & DOWN keys, nd the parameter that you wish to modify
4) Press and release the SET key once more. The upper display will show the name of the blinking
parameter
5) Use the UP & DOWN to adjust the parameter value
6) Press and release SET to save the parameter value
7) Return to step 3) or press ESC several times to return to the normal display
Nr. KEY press and release press and hold for about 3 seconds Notes
A
p UP
•Alarms Menu (always visible)*
• Scroll
• Increase values
/
*HACCP alarms/system alarms
if present
B ESC
• Exit
• Functions menu
• Manual defrost
• Return to Main Menu
C SET
• Display SetPoint / probe values / time*
• Conrm values
• Access value edit mode
(upper display blinking)
Access Parameter Edit mode
D
q DOWN
• Scroll
• Decrease values
• Display instrument INFO**
/ **See Technical Support
E
START/STOP
RESET
• Start Climate Prole
• Stop Climate Prole
• Reset Climate Prole See Climate Proles
F ON/OFF / Switch device On/O
G LIGHT / Switch light on/o
H AUX1/2 Activate destratication fans Activate destratication fans
