64
UI08 Configuration of led9 0…32 27 0 27 num
UI09 Configuration of led10 0…32 28 0 28 num
UI10 Configuration of led11 0…32 29 0 29 num
UI12 Select main set point display 0…1 0 - 0 num
UI13 Select main display 0…6 2 2 2 num
UI20 Installer password 0…255 1 1 1 num
UI21 Manufacturer password 0…255 2 2 2 num
UI22 Unit of temperature measurement 0…1 0 0 0 num
UI23 Unit of pressure measurement 0…1 0 0 0 num
ST Folder
St01 Central/lateral set point 0…1 1 1 1 num
St02 Select Hot/cold operating modes 0…1 1 1 1 num
St03 Absolute/relative alarms 0…1 0 0 0 num
St04 Regulators configuration 0…3 1 1 1 num
CP Folder
CP00 Regulation setpoint CP01…CP02 230 230 230 CFBP
CP01 Setpoint bottom limit -999…CP02 -100 -100 -100 CFBP
CP02 Setpoint upper limit CP01…9999 700 700 700 CFBP
CP03 Proportional band 0…9999 50 50 50 CFBP
CP04 Delta minimum cut-off 0…9999 20 20 20 CFBP
CP05 Delta saturation cut-off 0…9999 20 20 20 CFBP
CP06 Hysteresis minimum cut-off 0…9999 10 10 10 CFBP
CP07 Hysteresis saturation cut-off 0…9999 10 10 10 CFBP
CP08 Enable minimum cut-off 0…1 1 1 1 num
