Eliwell IDplus 902 - IDPlus 902;961 Connections; IDPlus 902 Terminal Connections; IDPlus 961 Terminal Connections

IDPLUS 902/961 CONNECTIONS
IDPlus 902: TERMINALS IDPlus 961: TERMINALS
OUT1
OUT1 relay 2-3-4: 12Va or 5-6-7: 230Va
1-2: Compressor relay
Supply
6-7: models 12Va or 3-4: models 230Va
Supply
6-7: models 12Va or 3-4: models 230Va
N-L 230V
a power supply N-L 230Va power supply
10-9 Probe Pb1 10-9 Probe Pb1
10-11 Digital Input 1/ Pb3 probe 10-11 Digital Input 1/ Pb3 probe
TTL TTL Input TTL TTL Input
version with Pb3
(H11=0 and H43=y)
version with D.I.1
(H11≠0 and H43=n)
Pb3
9
10
Pb1
11
8
D.I.1
9
10
Pb1
11
8
Probe
connections
MODELS 12V~/c
2 3 4 5 6 7
ID
PLUS
902
Load
N
L
8 9 10 11
TTL
Power
Supply
MODELS 12V~/c
I
D
PLUS
961
1
2
6 7
N
L
8 9 10 11
TTL
Power
Supply
MODELS 230V~
I
D
PLUS
961
N
L
1
2
3 4
8 9 10 11
TTL
Power
Supply
MODELS 230V~
3 4 5 6 7
I
D
PLUS
902
Load
N
L
8 9 10 11
TTL
Power
Supply
