Eliwell IWP 760 LX User Manual

8/14
NOTE: At level 1 the folders will only display all the level 1 parameters. At level 2 the folders will only display all the
level 2 parameters.
IWP 760 LX Fan Condenser
PAR. DESCRIPTION
RANGE DEFAULT
LEVEL** U.M.
OAO High and low temperature alarm delay after dis-
abling digital input
(door closed)
0...10 0
2 ore
Alarms-AL label
tdO Time out after alarm signal when disabling digital
input (door open)
0...250 0
2 min
tAO (5) Temperature alarm delay time
0...250 0
1 min
dAt Alarm for defrosting ended due to time out.
n=alarm not active
y=alarm active
n/y n
2 flag
AOP Polarity of alarm output:
0 = alarm active and output disabled;
1 = alarm active and output enabled
0/1 1
2 flag
PbA Configuration of temperature alarm on probe 1
and/or 3:
0=on probe 1 (thermostat control)
1=on probe 3 (display)
2=on probe 1 and 3 (thermostat control and display)
3=on probe 1 and 3 (thermostat control and display)
on external threshold
0/1/2/3 0
2 num
SA3 Probe 3 alarm set point
-50.0...150.0 0
2 °C/°F
dA3 Probe 3 alarm differential
-30.0...30.0 2.0
2
°C/°F
Light & digital inputs Lit Label
dSd Light relay enable from door switch.
n = door open, light does not turn on;
y = door open, light turns on (if it was off)
n/y y
2 flag
dLt Light relay disabling delay after closing door if
“dSd”=y
0...31 0
2 min
OFL Light relay disabled even if disabling delay
“dLt” is active
n/y n
2 flag
dAd Delay in enabling digital inputs DI1, DI2
0...250 0
2 min
dOd Digital input switches off loads
n/y n
2 flag
rLO Controllers disabled by external alarm:
0= no resources are disabled
1= disables compressor and defrosting
2=disables compressor, defrosting and fan
0/1/2 0
2 num
tA3 Probe 3 alarm delay time
0...59 0
2 min
ArE Enables alarm relay if alarms refer to probe 3:
0= does not enable alarms if alarms/errors on
probe 3
1= enables alarm relay if alarms/errors
on all probes
2= enables alarm relay ONLY if alarms/errors on probe 3
0...2 0
2 min
dI3 Delay in enabling digital inputs DI3, DI4
0...255 0
2 min/sec
PEA Enables forced behaviour from door light and/or external alarm:
0=disabled function 1=associated with door light
2=associated with external alarm
3=associated with door light and/or external alarm
0/1/2/3 0
2 num
dCO Delay in enabling compressor with consensus
0...250 0
2 min
dFO Delay in enabling fans with consensus
0...250 0
2 min
1 2
10 2
0 1
0 2
1 2
0 2
0 2
2.0
2
y 2
0 2
y 2
0 2
y 2
0 2
0 2
0 2
0 2
0 2
0 2
0 2
CUSTOM SETTINGS
DEFAULT - LEVEL
dIU Unit of measurement for D.I.1 and D.I.2 activation
delay
0=minutes; 1=seconds
0/1 -
- flag
0 2
dOA Forced behaviour from digital input
0=no enabling 1=compressor enabled
2=fans enabled
3=compressor and fans enabled
0/1/2/3 0
2 num
0 2
